FX Series Push-Pull Fiber Optic Connectors
¥0.00
Product Overview
● Plug-in/plug-out design, blind-pluggable, enabling quick connection and disconnection.
● Multiple key identification features, with anti-misinsertion function
. ● Suitable for aviation, electronics, and marine systems for multi-channel optical communication
. ● Features include sealing, environmental resistance, and long lifespan.
Main Technical Specifications
Mechanical Performance
● Mechanical Life : 1000 cycles of insertion and removal
● Shock : Peak acceleration 2940m/s², duration 3ms
● Vibration : 10～2000Hz, acceleration 147m/s²
● Tensile Strength : ≥110N (plug assembly)
Environmental Performance
● Temperature Range: -55°C to +85°C
● Salt Spray : Class F: 96h Class C: 500h
Optical Performance
● Insertion Loss: ≤0.6dB (48-core MT ≤1.0dB)
