Описание Товара
1×9 155 Мбит/с 20 КМ 1310/1550 нм Одномодовый оптоволоконный оптический FP модуль
Функция
- соответствует стандарту IEEE802.3z
- Стандартный пакет 1×9
- Оптический интерфейс с одним разъемом SC
- 1310 нм /1550 нм лазер FP, расстояние 20 км
- SD: Логический уровень PECL, источник питания 3,3 в или 5 В.
Приложение
- Gigabit Ethernet
- 1 ИНТЕРФЕЙС Fibre Channel
- Сеть оптического доступа
- Другие оптические ссылки
Основная Информация
| Модель №. | FT-9G-B35F-20D/FT-9G-B53F-20D |
| Содержание информации | Данные |
| Состояние | Новый |
| длина волны | 1310 нм |
| разъем | sc/st/fc |
| тип волокна | одноволоконный режим |
| источник питания | 3,3 в/5 в. |
| Торговая Марка | F-tone Networks |
| Поддержка сети | Ethernet |
| Сертификация | CE, ISO, RoHS |
| скорость передачи данных | 155 мбит/с. |
| расстояние | 20 км |
| пакет | 1X9 |
| гарантия | 1 год |
| Транспортная Упаковка | антистатический блок |
| Происхождение | Китай |
Важное уведомление
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they are applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or other. Further details are available from any F-tone Networks sales representative.
Power and Wavelength Testing
Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.
Traffic Testing
Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.
Optical Performance Testing
Test the transceivers’ eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.
End Face Testing
Check the end face of the transceivers and keep them clean for more stable data transmission, better performance, and durability.
